ASROCK Rack 2U24E-GENOA2 User Manual

Server/workstation
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2U24E-GENOA2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK Rack 2U24E-GENOA2

Summary of Contents for ASROCK Rack 2U24E-GENOA2

  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of...
  • Page 3 • This product is not suitable for use with visual display work place devices according to §2 of the the German Ordinance for Work with Visual Display Units. • Only skilled person and Instructed person can remove the chassis covers to access the inside of the system. ASRock Rack’s Website: www.ASRockRack.com...

  • Page 4: Replaceable Batteries

    Replaceable Batteries CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Warning When removal of the chassis lid required for servicing: - Turn off power and unplug any power cords/cables, and - Reinstall the chassis lid before restoring power.

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Shipping Box Contents Specifications Chapter 2 Server System Overview System Components Internal Features System Front Panel System Rear Panel Front Control Panel Buttons and LEDs PSU LED Drive Tray LEDs Chapter 3 Hardware Installation and Maintenance Server Top Cover Hard Drive (Front Side) Hard Drive (Internal)

  • Page 6: Chapter 1 Introduction

    2U24E-GENOA2 Chapter 1 Introduction Thank you for purchasing 2U24E-GENOA2, a reliable barebone system produced under ASRock Rack’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock Rack’s commitment to quality and endurance. This guide provides the instructions of insertion and extraction of chassis components, such as chassis covers, system fans, power supplies, hard disk drive trays, and other main components this system supports.

  • Page 7: Shipping Box Contents

    1.1 Shipping Box Contents Item Quantity Server Barebone :2U24E-GENOA2 CPU Heatsink Rail Kit Accessory Box - 2 Power cords - 1 Quick installation guide 2 M.2 screws If any items are missing or appear damaged, contact the authorized dealer.

  • Page 8: Specifications

    2U24E-GENOA2 1.2 Specifications 2U24E-GENOA2 System Form Factor 2U Rackmount Dimensions 770.0 x 438.0 x 86.4mm (30.3'' x 17.2'' x 3.4'') Support MB GENOA2D24TM3-2L+/2U Front Panel Buttons Power, Reset, UID LEDs Power, LAN 1/2, HDD Activity, System status I/O Ports 1 Type-A (USB3.2 Gen1), 1 Type-A (USB2.0), 1 DB15 (VGA)
  • Page 9 2 RJ45 (1GbE) RJ45 1 dedicated IPMI System BIOS BIOS Type AMI UEFI BIOS; 256Mb (32MB) SPI Flash ROM ASRock Rack Instant Flash, ACPI 6.4 and abouve compliance BIOS Features wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
  • Page 10 2U24E-GENOA2 Hardware Monitor Temperature CPU, MB, Card side Temperature Sensing Fan Tachometer CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Fan Multi-Speed Control P0_VDDCR_CPU0, P0_VDDCR_CPU1, P0_VDDCR_SOC, P0_VDD_18_DUAL, P0_VDD_11_S3, P0_VDDIO, P1_ Voltage VDDCR_CPU0, P1_VDDCR_CPU1, P1_VDDCR_SOC, P1_ VDD_18_DUAL, P1_VDD_11_S3, P1_VDDIO, +BAT, +12V,...

  • Page 11: Chapter 2 Server System Overview

    Chapter 2 Server System Overview This chapter provides diagrams showing the location of important components of the server system. 2.1 System Components Riser-Card Assembly 2 1 FHHL PCIe5.0 x16 card / 2 FHHL PCIe5.0 x8 cards Riser-Card Assembly 3 Riser-Card Assembly 1 1 HHHL PCIe5.0 x8 card 1 FHHL PCIe5.0 x16 card / 2 FHHL PCIe5.0 x8 cards 2 Power Supply Units...

  • Page 12: Internal Features

    2U24E-GENOA2 2.2 Internal Features...
  • Page 13 Description 1+1 power supply units 2-fixed 2.5'' NVMe (PCIe5.0 x4) carrier Riser-Card Assembly 1: 1 FHHL PCIe5.0 x16 or 2 FHHL PCIe5.0 x8 cards 1 OCP NIC 3.0 card slot Riser-Card Assembly 2: 1 FHHL PCIe5.0 x16 or 2 FHHL PCIe5.0 x8 cards Riser-Card Assembly 3: 1 HHHL PCIe5.0 x8 card Server board (GENOA2D24TM3-2L+/2U)

  • Page 14: System Front Panel

    2U24E-GENOA2 2.3 System Front Panel Description 1 USB2.0 port + 1 USB3.2 Gen1 port 24 hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays 1 VGA port Front control panel...

  • Page 15: System Rear Panel

    2.4 System Rear Panel Redundant PSU 1+1: Only one PSU is allowed to be removed while the server is running. Description Power supply unit 1 HHHL PCIe5.0 x8 card slot (Riser Card Assembly 3) I/O Shield (depends on the specification of the server board) 1 FHHL PCIe5.0 x16 or 2 FHHL PCIe5.0 x8 card slots (Riser Card Assembly 2) OCP NIC 3.0 (PCIe5.0 x16) card slot 1 FHHL PCIe5.0 x16 or 2 FHHL PCIe5.0 x8 card slots (Riser Card Assembly 1)

  • Page 16: Front Control Panel Buttons And Leds

    2U24E-GENOA2 2.5 Front Control Panel Buttons and LEDs Description USB 2.0 port USB 3.2 Gen1 port Power button and LED System event LED LAN2 activity LED VGA port UID button and LED System reset button HDD activity LED LAN1 activity LED Power Button Press the power switch button to toggle the system power on and standby/sleep modes.
  • Page 17 Status LED Definitions Power LED Status Description Blue Power on Power off ID LED Status Description Blue System identification is active System identification is disabled LAN1, LAN2 LEDs Status Description Green Link between system and network No access System Event LED Status Description Signal error...

  • Page 18: Psu Led

    2U24E-GENOA2 2.6 PSU LED PSU LED PSU Status LED Status Description Green Output on and ok NO AC power to all power supplies Amber - AC cord unplugged, or AC power lost; with a second power supply in parallel still with AC input power.

  • Page 19: Drive Tray Leds

    2.7 Drive Tray LEDs Description Hard drive activity LED (Green) Hard drive status LED (Blue/Red) Status LED Definitions Drive Activity LED Drive Status LED Description Activity Locate Fail Drive Not Present Drive Present, No Act Drive Present, Act Locate (Identify) Fail Rebuild...

  • Page 20: Chapter 3 Hardware Installation And Maintenance

    2U24E-GENOA2 Chapter 3 Hardware Installation and Maintenance This chapter helps user to assemble the chassis and install components. Before You Begin Before working with the server, pay close attention to the “Important Safety Instructions” at the beginning of this manual.

  • Page 21: Server Top Cover

    3.1 Server Top Cover Removing the Top Cover 1. Before removing the top cover, power off the server and unplug the power cord. 2. The system must be operated with the chassis top cover installed to ensure proper cooling. 3. Front top cover and rear top cover can be removed and installed separately. 1.
  • Page 22 2U24E-GENOA2 3. Remove the screws securing the top front cover to the chassis. 4. Push the cover forward to remove it from the locked position. Then lift up and remove the cover.

  • Page 23: Installing The Top Cover

    Installing the Top Cover 1. Lower the top front cover on the chassis, making sure the side latches align with the cutouts. 2. Slide the top front cover toward the rear side of the chassis. Then secure the cover with the screws.
  • Page 24 2U24E-GENOA2 3. Lower the top rear cover on the chassis, making sure the side latches align with the cutouts. 4. Slide the top rear cover toward the front side of the chassis. Then secure the cover with the screws.

  • Page 25: Hard Drive (Front Side)

    3.2 Hard Drive (Front Side) The hard disk trays on the front side of the chassis support 2.5" hot-swappable hard disk drives. Installing a 2.5” Hard Drive to the Chassis 1. Press the locking latch on the drive bay to rotate the lever out.
  • Page 26 2U24E-GENOA2 2. Slide a 2.5" hard drive into the bay until the drive is fully seated. 3. Push in the lever to lock the drive in place.

  • Page 27: Hard Drive (Internal)

    3.3 Hard Drive (Internal) Removing the Hard Drive Carrier from the Chassis 1. Release the thumbscrew secureing the hard drive carrier to the chassis. 2. Push the carrier straight back to remove it from the locked position. Lift up and remove the carrier.
  • Page 28 2U24E-GENOA2 Installing a 2.5” Hard Drive to the Chassis 1. Slide the 2.5" hard drives into the carrier with the printed circuit board side facing down. Carefully align the mounting holes on the hard drives and the carrier. 2. Secure the hard drives with the screws.

  • Page 29: Power Supply

    2. In a redundant system, it does not need to power down the server. 2U24E-GENOA2 system can accommodate two power supplies in the bay at the rear of the chassis. Each unit provides up to 2600 Watts of power.
  • Page 30 2U24E-GENOA2 Installing the Power Supply Unit 1. Align the power supply unit with the power supply slot. Ensure that the LED appears on the upper right when installing the power supply unit. 2. Carefully slide the PSU all the way into the power supply bay until it clicks into place.

  • Page 31: System Fan

    3.5 System Fan The system supports hot-swappable system fans. Replacing the System Fan 1. Lift to remove the failed fan. 2. Align the fan connector on the bottom of the replacement fan with the fan connector in the fan cage. 3.

  • Page 32: Add-In Card

    2U24E-GENOA2 3.6 Add-in Card 1. When installing an add-in card to the chassis, make sure the riser card assembly have pre- installed on the serverboard. 2. Before installing the add-in card, power off the server and unplug the power cord.
  • Page 33 4. Remove the screw securing the plate cover to the bracket. 5. Slide the plate cover out sideways. 6. Install an add-in card to bracket. 7. Tighten the screw to secure the add-in card.
  • Page 34 2U24E-GENOA2 8. Install the riser-card assembly to the chassis. Align the plate of the add-in card with the openings in the back of the chassis. 9. Hand-tighten the thumbscrews on the bracket. 10. Use screws to secure the assembly to the chassis.

  • Page 35: Ocp Card

    3.7 OCP Card Installing the OCP Card 1. Hand-release the thumbscrew securing the slot cover to the chassis. 2. Remove the slot cover.
  • Page 36 2U24E-GENOA2 3. Install an OCP card to the slot. 4. Make sure the card is well seated and hand-tighten the thumbscrew on the face plate.

  • Page 37: Installing The Cpu (Lga6096 Socket)

    Appendix A Installing the CPU (LGA6096 Socket) 1. Before inserting the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 38 2U24E-GENOA2...
  • Page 39 Carr ier Frame with CPU Rail Frame Please make sure that the carrier frame with CPU is closely attached to the rail frame while inserting it. Install the carrier frame with CPU. Don’t separate them.
  • Page 40 2U24E-GENOA2...
  • Page 41 Set your torque wrench to 1.54 in-lb. One fourth a turn each time. Tighten the screws in a sequential order 1 > 2 > 3 > 4 > 5 > 6. Loosen the screws in a reverse order. 10-4 10-2 10-5 10-6 10-1...

  • Page 42: Installing The Memory Modules (Dimm)

    2U24E-GENOA2 Installing the Memory Modules (DIMM) The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if forcing the DIMM into the slot at incorrect orientation.For more information about DIMM installation, please refer to the User Manual that comes...

  • Page 43: Block Diagram (Genoa2D24Tm3-2L+/2U)

    Block Diagram (GENOA2D24TM3-2L+/2U)

  • Page 44: Installing The Server In A Rack

    2U24E-GENOA2 Appendix B Installing the Server in a Rack This section describes how to rackmount the 2U24E-GENOA2 server with slide rail assembly. The rails installation instructions in this manual are example only, the actual rail assembly procedure may differ slightly.
  • Page 45 Rail Kit Installation Guide Kit Contents (1) Rail (2 pcs) Screw Sack optional but all required for rack shipping) ⓐ M4x4L screw (2 pcs) Rail Kit Installation Guide ⓑ M5x10L screw (2 pcs) Kit Contents ⓒ Washer 2 pcs (1) Rail (2 pcs) Screw Sack optional but all required for rack shipping) ⓐ...
  • Page 46 2U24E-GENOA2 Install System into Rack CAUTION! (4)Install the system into the rails. Ensure the ball bearing <1> Pull out the intermediate rail retaineris locked forward member until fully extended. in each intermediate Click! rail member. <2> Carefully align and insert the...

  • Page 47: Contact Information

    Contact Information Contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.
