Installation Instructions
REV 4 11/15/21
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2818
Product: Running Boards
Application:
Land Rover RR Sport 2014+
Land Rover Discovery 2017+
Level of Difficulty: 1 2
Installation Time: 90 min
3
4 5
Advertisement
Related Manuals for Romik 2818
Summary of Contents for Romik 2818
- Page 1 Part No. 2818 Product: Running Boards Application: Land Rover RR Sport 2014+ Installation Instructions Land Rover Discovery 2017+ Level of Difficulty: 1 2 Installation Time: 90 min REV 4 11/15/21 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2818 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install provided HTC 279 U bolt as shown on Figure 1 Step 3: Attach front bracket onto U bolt Figure 2...
- Page 3 Installation Instructions 2818 Bracket Kit Step 6: Locate rear bracket mounting area Figure 6. Install provided HTC 284 and HTC 240 Figure 7. Step 7: Install rear bracket as shown Figure 8. Do not tighten Figure 7 Figure 6 HTC 284...
- Page 4 NOTE: Use of power tools will damage the bottom of the running board and void your warranty. 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1.
