Installation Instructions
REV 2 02/25/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2617
Product: Running Boards
Application:
Fiat 500X 2015+
Jeep Renegade 2015+
Level of Difficulty:
1
2 3 4 5
Installation Time: 60 Min
Advertisement
Table of Contents
Related Manuals for Romik 2617
Summary of Contents for Romik 2617
- Page 1 Part No. 2617 Product: Running Boards Application: Fiat 500X 2015+ Installation Instructions Jeep Renegade 2015+ Level of Difficulty: 2 3 4 5 Installation Time: 60 Min REV 2 02/25/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2617 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Remove factory rubber plug Figure 1, Install HTC 262 as shown Figure 2 Figure 2...
- Page 3 Installation Instructions 2617 Bracket Kit Step 6: Install extra support bracket as shown on Figure 12 Figure 12 Figure 11 Step 7: Remove rubber plug for rear bracket area as show Figure 13, Install provided HTC 240 as shown Figure 15. Attach rear main bracket as shown Figure 16. Attach extra support to main rear bracket using supplied M10 hardware Figure 17.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
