Installation Instructions
REV 4 05/01/22
Hardware
Torque Aluminum Torque Steel to Steel
M6 Bolt
3 ft-lbs.
M8 Bolt
7 ft-lbs.
M10 Bolt
16 ft-lbs.
M12 Bolt
28 ft-lbs.
14 ft-lbs.
35 ft-lbs.
64 ft-lbs.
112 ft-lbs.
Part No.
Product: Running Boards
Application:
Dodge Ram 1500 2009-2018
Dodge Ram HD 2019+
Level of Difficulty: 1
Installation Time: 60 Min
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty. If
you have any questions, please contact our
technical team at 1-866-717-6645
2013 / 2015
Crew Cab
2
3 4 5
Advertisement
Related Manuals for Romik 2013
Summary of Contents for Romik 2013
- Page 1 Part No. 2013 / 2015 Product: Running Boards Application: Crew Cab Dodge Ram 1500 2009-2018 Installation Instructions Dodge Ram HD 2019+ Level of Difficulty: 1 3 4 5 Installation Time: 60 Min REV 4 05/01/22 Hardware Torque Aluminum Torque Steel to Steel...
- Page 3 Installation Instructions 2013 / 2015 Bracket Kit Thank you for choosing the Romik DRP System. This system allows you to adjust the brackets from 0 to 3-inch drop. If you ordered the optional DRP cover you can customize them to match the desired height by cutting on the lines inside the cover.
- Page 4 Installation Instructions 2013 / 2015 Bracket Kit Step 3: Install provided HTC 262 as shown on Figure 3, install main bracket as shown on Figure 4. Do not tighten Figure 3 Figure 4 HTC 262 Step 4: Install extra support bracket with supplied M6 hardware on all 3 locations Figure 5,attach using supplied M6 hardware Figure 6.
- Page 5 2X per year. Wash often with mild soap and make sure to remove all soap residue. Many car automatic carwashes use a strong soap, make sure to use enough water to remove all residue. For video instructions on how to clean your Romik products please click here https://romik.com/cleaning...
