Installation Instructions
REV 2 10/15/21
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
Part No.
2164
Product: Running Boards
Application:
Level of Difficulty: 1
Installation Time: 90 min
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Ford Escape 2020+
Ford Bronco Sport 2021+
2
3 4 5
Advertisement
Table of Contents
Related Manuals for Romik 2164
Summary of Contents for Romik 2164
- Page 1 Part No. 2164 Product: Running Boards Application: Ford Escape 2020+ Ford Bronco Sport 2021+ Installation Instructions Level of Difficulty: 1 3 4 5 Installation Time: 90 min REV 2 10/15/21 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2164 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install provided HTC 230 and HTC 226 on both front locations Figure 1. Proceed to install front bracket as shown on Figure 2.
- Page 3 Installation Instructions 2164 Bracket Kit Step 4: Using supplied wire, “pass” special bolt and plate through the large hole coming out of the smaller hole just above. Install plastic “klips” without letting go of wire to prevent losing the special bolt inside the chassis.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
