Installation Instructions
REV 1 01/13/2020
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2162
Product: Running Boards
Application:
Ford Explorer 2020+
Lincoln Aviator 2020+
Level of
Difficulty:1
2 3 4 5
Installation Time: 60 Min
Advertisement
Table of Contents
Related Manuals for Romik 2162
Summary of Contents for Romik 2162
- Page 1 Part No. 2162 Product: Running Boards Application: Ford Explorer 2020+ Installation Instructions Lincoln Aviator 2020+ Level of Difficulty:1 2 3 4 5 Installation Time: 60 Min REV 1 01/13/2020 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2162 Bracket Kit Instruction: Step 1: Remove plastic panels under vehicle, do not discard hardware as it will be re-used. Step 2: Locate front passenger mounting locations and hardware as per 1 page of this installation manual Step 3: Inner mounting area pull wire harness out of the way as bracket will be installed under the harness Figure 1.
- Page 3 Installation Instructions 2162 Bracket Kit Step 6: Locate middle bracket location and hardware Step 7: Install provided HTC 262 hardware as shown Figure 6 Step 8: Install middle bracket as shown Figure 7 do not tighten. Figure 7 Figure 6 HTC 262 Step 9: Install middle bracket running board base using supplied M10 hardware as shown on Figure 8.
- Page 4 Step 13: Proceed to last page of this manual for running board install instructions and torque values Step 14: After securing running boards proceed to trim plastic panels as needed. Step 15: This vehicle has 4 factory one time use fasteners Figure 12, replace with provided Romik fasterners. See Figure 13.
- Page 5 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
