Romik 2152 Installation Instructions

Running boards ford edge 2015+ lincoln mkx / nautilus 2016+

Installation Instructions

REV 4 10/15/21

Hardware

M6 Bolt

M8 Bolt

M10 Bolt

M12 Bolt

Torque Specifications

3 ft-lbs.

7 ft-lbs.

16 ft-lbs.

28 ft-lbs.

Part No.

Product: Running Boards

Application:

Ford Edge 2015+

Lincoln MKX / Nautilus 2016+

Level of Difficulty:

Installation Time: 60 min

ATTENTION: Use correct torque settings to avoid

damaging the running boards and or mounting

brackets. Failure to do so will void your warranty.

If you have any questions please contact our technical

team at 1-866-717-6645

2152 / 6211

2 3 4 5

Table of Contents

Need help?

Do you have a question about the 2152 and is the answer not in the manual?

Page 1 Part No. 2152 / 6211 Product: Running Boards Application: Ford Edge 2015+ Installation Instructions Lincoln MKX / Nautilus 2016+ Level of Difficulty: 2 3 4 5 Installation Time: 60 min REV 4 10/15/21 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
Page 3 Video Installation Installation Instructions 2152 / 6211 Bracket Kit Instruction: NOTE: This vehicle requires undercarriage panel trimming and use of a level. Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Using a utility knife cut a 4 ½...
Page 4 Installation Instructions 2152 / 6211 Bracket Kit Step 4: Locate rear bracket mouning area and remove material from cover as necessary Figure 7. Install provided HTC 230 as shown Figure 8 Figure 7 Figure 7 HTC 230 Step 5: Install rear bracket as shown Figure 8, Install running board base plate using supplied M10 harware.
Page 5 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.

6211
