Installation Instructions
REV 3 03/24/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2328
Product: Running Boards
Application:
Hyundai Tucson 2016+
Kia Sportage 2017+
Level of Difficulty: 1
2
Installation Time: 60 Min
3 4 5
Advertisement
Related Manuals for Romik 2328
Summary of Contents for Romik 2328
- Page 1 Part No. 2328 Product: Running Boards Application: Hyundai Tucson 2016+ Installation Instructions Kia Sportage 2017+ Level of Difficulty: 1 3 4 5 Installation Time: 60 Min REV 3 03/24/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2328 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Locate and remove factory rubber plug Figure 1. Install HTC 230 as shown Figure 2...
- Page 3 Installation Instructions 2328 Bracket Kit Step 6: Install middle bracket using supplied M6 hardware Figure 9. Do not tighten Figure 9 Step 7: Locate rear bracket install area and remove factory rubber plug Figure 10 Install HTC 230 as shown...
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
