Installation Instructions

REV 2 05/01/22

Hardware

Torque Aluminum

M6 Bolt

3 ft-lbs.

M8 Bolt

7 ft-lbs.

M10 Bolt

16 ft-lbs.

M12 Bolt

28 ft-lbs.

Torque Steel to Steel

14 ft-lbs.

35 ft-lbs.

64 ft-lbs.

112 ft-lbs.

Part No.

2820

Product: Running Boards

Application:

Land Rover Discovery Sport

Level of Difficulty: 1 2

Installation Time: 120 Min

ATTENTION: Use correct torque settings to avoid

damaging the running boards and or mounting

brackets. Failure to do so will void your warranty. If

you have any questions, please contact our technical

team at 1-866-717-6645

4 5

Need help?

Do you have a question about the 2820 and is the answer not in the manual?

Page 1 Part No. 2820 Product: Running Boards Application: Land Rover Discovery Sport Installation Instructions Level of Difficulty: 1 2 Installation Time: 120 Min REV 2 05/01/22 Hardware Torque Aluminum Torque Steel to Steel ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
Page 3 Important Install Tip: When installing Romik HTC inserts follow the sequence below. Make sure the HTC is seated correctly and do not use power tools as this will only spin the insert and possibly damage it. Test by tugging on it before installing braket.
Page 4 Installation Instructions 2820 Bracket Kit Step 3: Locate rear bracket area, and install supplied HTC 230 with HTC269 as shown Figure 3. Install extra support bracket as shown Figure4. Do not tighten. Figure 3 Figure 4 Step 4: Locate rear bracket area, and install supplied HTC 230 with HTC 269 as shown Figure 5. Install rear bracket as shown Figure 6.
Page 5 2X per year. Wash often with mild soap and make sure to remove all soap residue. Many car automatic carwashes use a strong soap, make sure to use enough water to remove all residue. For video instructions on how to clean your Romik products please click here https://romik.com/cleaning...
