Installation Instructions
REV 3 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
2135 / 6210
Product: Running Boards
Application:
Ford Escape 2013-2019
Lincoln MKC 2015+
Level of Difficulty:
1
2 3 4 5
Installation Time: 60 min
Advertisement
Table of Contents
Related Manuals for Romik 2135
Summary of Contents for Romik 2135
- Page 1 Part No. 2135 / 6210 Product: Running Boards Application: Ford Escape 2013-2019 Installation Instructions Lincoln MKC 2015+ Level of Difficulty: 2 3 4 5 Installation Time: 60 min REV 3 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs.
- Page 2 Video Installation Installation Instructions 2135 / 6210 Bracket Kit Instruction: Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install provided HTC 230 on both front locations Figure 1. Proceed to install front bracket as shown on Figure 2.
- Page 3 Installation Instructions 2135 / 6210 Bracket Kit Step 4: Locate main rear bracket mounting area, install provided HTC 243 as show Figure 4. Figure 4 Step 5: Install extra support as shown on Figure 5. Attach main rear bracket as shown on Figure 6. Connect extra support to main rear bracket using supplied M10 hardware as shown on Figure 7.
- Page 4 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
