Serial Devices

To install a serial device such as a printer or an external
modem, you need a cable with a female 9-pin connector.
NOTE
stall the appropriate printer driver through the Win-
dows Control Panel. See the online Windows
QuickStart Guide or Using Windows 95 for instruc-
tions on using the Control Panel.
Follow these steps to connect a serial device to your NEC
Versa 2200C.
Check that both the NEC Versa 2200C and the device
1.
power are off.
2. Open the left-rear port cover and locate the serial port,
(second from left).
3. Align and connect the 9-pin connector with the serial
port on the system. Secure the connection with the
screws provided.
4. Align and connect the other end of the cable to the ap-
propriate port on the device. Secure the connections with
the screws provided.
Connect the power cable to the device and a properly
5.
grounded wall outlet.
Turn on power to the system and then to the device.
6.
NOTE
to use it. See the device guide for instructions.
When you connect a printer, be sure you in-
Make sure your device is online before trying
Learning to Use the Hardware 2-15
