External Keyboard

You can add a full-size PS/2-style keyboard to your NEC
Versa 2200C using the Plug and Play feature. You cannot
use the system keyboard while an external keyboard is con-
nected. However, when you press the numlock key combi-
nation (
keyboard only is enabled.
If you want to attach both an external keyboard and a PS/2-
style external mouse at the same time, use the optional NEC
Y-adapter. See the online NEC Versa 2200C Options
Catalog.
Follow these steps to connect an external keyboard to
your system.
Check that the NEC Versa 2200C is in Suspend mode or
1.
powered off.
Make sure the NEC Versa 2200C is in Suspend
mode whenever you add or remove a keyboard.
Doing so with the power on in Active mode may
damage either the keyboard controller chip or the
keyboard.
Connect the keyboard cable connector to the keyboard
2.
port on the system. (The keyboard/mouse port is the
first one on the left rear of the system.)
2-16 Learning to Use the Hardware
), the numeric keypad on the external
Fn+NumLock
!
CAUTION
