External Monitor

You can add a standard external monitor to your NEC
Versa 2200C. You need a display signal cable (usually
provided with the monitor). One end of the cable must have
a 15-pin connector for the system. (See the back of the NEC
Versa 2200C, behind the right-rear cover, for the monitor
connector.)
Follow these steps to connect an external monitor to your
NEC Versa 2200C.
Check that the NEC Versa 2200C is in Suspend mode or
1.
powered off and the monitor power switch is turned off.
NOTE
mode or powered off while the monitor is being
connected.
Open the right-rear cover of the system.
2.
3. Attach the 15-pin cable connector to the video port on
the system. (The video port is the second from the right.)
Secure the cable connection with the screws provided.
The NEC Versa 2200C must be in Suspend
