39. BNC INPUT

Function
The external control equipment sets the BNC SELECT of the plasma monitor.
Transmission Data
DFH 80H 60H 8CH 01H DATA00 CKS
DATA00 : BNC SELECT
ACK
The plasma monitor returns the following ACK when setting the BNC SELECT:
7FH 60H 80H 8CH 01H DATA00 CKS
DATA00 : BNC SELECT
40. RGB Select
Function
The external control equipment sets the RGB SELECT of the plasma monitor.
Transmission Data
DFH 80H
60H
DATA00
ACK
7FH 60H 80H 8BH 01H
DATA00
01H : RGB
02H : Component
04H : SCART1(*:Only Europe can be chosen.)
05H : SCART2(*:Only Europe can be chosen.)
01H : RGB
02H : Component
04H : SCART1(*:Only Europe can be chosen.)
05H : SCART2(*:Only Europe can be chosen.)
8BH 01H
DATA00 CKS
01H : AUTO
02H : STILL
03H : MOTION
04H : WIDE1
05H : WIDE2
06H : DTV
07H : WIDE3
08H : WIDE4
DATA00 CKS
01H : AUTO
02H : STILL
03H : MOTION
04H : WIDE1
34
