17. NR MODE Set

Function
The external control equipment sets the NR (Noise Reduction) mode of the
plasma monitor.
Transmission Data
DFH 80H 60H C0H 01H DATA00
DATA00: 01H : NR OFF
02H : NR-1
03H : NR-2
04H : NR-3
ACK
7FH 60H 80H C0H 01H DATA00
DATA00: 01H : NR OFF
02H : NR-1
03H : NR-2
04H : NR-3
18. BASS Gain Data
Function
The external control equipment changes the BASS gain data of the plasma
monitor.
Transmission Data
DFH 80H 60H 7FH 03H DATA00 DATA01 DATA02 CKS
DATA00 : USER PICTURE Gain Flag
DATA01 : BASS Gain Flag
DATA02 : BASS Gain
ACK
7FH 60H 80H 7FH 02H DATA00
DATA00 : USER PICTURE Gain Flag
DATA01 : BASS Gain Flag
CKS
CKS
05H
03H
F3H : -13
:
FFH : -01
00H : 0
01H : +01
:
0DH : +13
DATA01
05H
03H
21
CKS
