37. ALL RESET

Function
The external control equipment resets the user adjustment of the plasma
monitor.
Transmission Data
1FH 80H 60H 54H 00H CKS
ACK
3FH 60H 80H 54H 00H
38. Audio Select Set
Function
The external control equipment sets combinations of audio and video inputs for
the plasma monitor.
Transmission Data
DFH 80H 60H 70H 02H DATA00
DATA00 : AUDIO INPUT
DATA01 : VISUAL INPUT
ACK
The plasma monitor returns the following ACK when the input is switched.
3FH 60H 80H 70H 00H CKS
* The plasma monitor returns "Not Available" when selecting the video input
same as the one set at one of the AUDIO 1 to 3.
Example:
The plasma monitor returns "Not Available" when selecting the VIDEO1 for
AUDIO2 or VIDEO3 after VIDEO1 has been set to AUDIO1.
CKS
DATA01
01H : AUDIO1
02H : AUDIO2
03H : AUDIO3
01H : VIDEO1
02H : VIDEO2
03H : VIDEO3
05H : HD(HD1orDTVorDTV1)
06H : HD2(DTV2)
07H : RGB1/PC1
08H : RGB2/PC2
0CH : RGB3/PC3
0DH : HD3(SCART3)
33
CKS
