57.MULTI MODE Request
Function
External control apparatus can know the MULTI MODE information on a
plasma monitor.
Transmission Data
1FH 80H 60H 3BH 00H CKS
ACK
7FH 80H 60H 3BH 02H DATA00 DATA01 DATA02 CKS
DATA00 (SCREEN DIVIDER SETTING)
01H : Single mode
02H : Multi mode 1 screens
03H : Multi mode 4 screens
04H : Multi mode 9 screens
05H : Multi mode 16 screens
06H : Multi mode 25 screens
DATA01 (POSITION OF DIVIDE)
01H : Upper left selected (4 screens)
02H : Upper right selected (4 screens)
03H : Lower right selected (4 screens)
04H : Lower left selected (4 screens)
07H : Top left selected (9 screens)
08H : Top middle selected (9 screens)
09H : Top right selected (9 screens)
0AH : Middle left selected (9 screens)
0BH : Middle centerselected (9 screens)
0CH : Middle rightselected (9 screens)
0DH : Bottom leftselected (9 screens)
0EH : Bottom middle selected (9 screens)
0FH : Bottom right selected (9 screens)
10H : position1(16 screens,refer to figure1)
11H : position2(16 screens,refer to figure1)
18H : position9(16 screens,refer to figure1)
19H : position10(16 screens,refer to figure1)
1FH : position16 (16 screens,refer to figure1)
:
:
55
