63.GAMMA GAIN Data

Function
External control apparatus changes Gamma of a plasma monitor.
Transmission Data
DFH 80H 60H 13H 02H DATA00 DATA01 CKS
DATA00: GAMMA FLAG
DATA01: GAMMA
ACK
7FH 60H 80H 13H 01H DATA00 CKS
DATA00: GAMMA FLAG
64.Running Sense
Function
External control apparatus grasps the power supply state of a plasma monitor.
A plasma monitor is made to recognize connection of PC CONTROL.
Transmission Data
1FH 80H 60H 88H 00H CKS
ACK
7FH 60H 80H 88H 01H DATA CKS
DATA: Bit0:Connect Condition
Bit1 0: Fixed
Bit2:Power Status
Bit3 0: Fixed
Bit4 0: Fixed
Bit5 0: Fixed
Bit6 0: Fixed
Bit7 0: Fixed
0: No connection
1: Connected
1:-
0:POWER ON
1:POWER OFF(STANBY)
01H : Gamma change
00H :1
01H :2
02H :3
03H :4
01H : Gamma change
60
