- Page 2 Important Information Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE LCD COLOR MONITOR: About the Symbols To ensure safe and proper use of the product, this manual uses a number of symbols to prevent injury to you and others as well as damage to property.
- Page 3 WARNING Handling the power cord. Do not scratch or modify the cord. • Do not place heavy objects on the cord. • Do not let the weight of the product rest on the cord. • Do not cover the cord with a rug, etc. •...
- Page 4 WARNING Do not install the product in the locations below: • Poorly ventilated spaces. • Near a radiator, other heat sources, or in direct sunshine. • Continual vibration areas. • Humid, dusty, steamy, or oily areas. • An environment where there are corrosive gases (sulfur dioxide, hydrogen sulfide, nitrogen dioxide, chlorine, ammonia, ozone, etc.).
- Page 5 WARNING Stability Hazard. The product may fall, causing serious personal injury or death. To prevent injury, this product must be securely attached to the floor/wall in accordance with the installation instructions. Many injuries, particularly to children, can be avoided by taking simple precautions such as: •...
- Page 6 CAUTION Handling the power cord. The monitor should be installed close to an easily accessible power outlet. REQUIRED When connecting the power cord to the product’s AC IN terminal, make sure the connector is fully and firmly inserted. An incomplete connection of the power cord may cause overheating of the plug; it allows dust to get on the plug connection, which can lead to a fire.
- Page 7 CAUTION Incorrect usage of batteries can result in leaks or bursting. • Use the specified batteries only. • Insert batteries matching the (+) and (–) signs on each battery to the (+) and (–) signs of the battery compartment. • Do not mix battery brands.
- Page 8 N OTE: This product can only be serviced in the country where it was purchased. MultiSync is a trademark or registered trademark of Sharp NEC Display Solutions, Ltd. in Japan and other countries. Intel and the Intel logo are trademarks of Intel Corporation or its subsidiaries.
-
Page 9: Installing An Option Board
Installing an Option Board You can install Option Boards that are compatible with Intel Smart Display Module Small (Intel SDM-S) and Intel Smart ® ® ® Display Module Large (Intel SDM-L) specifications. ® 1. Turn off the main power switch. 2. - Page 10 6. To close the opening of the slot you did not use, reattach the SLOT COVER ( a or b ) with the removed screws (See Figure 1). When attaching the SLOT COVER a or b , use the holes (A) shown below in the SLOT COVER (Figure 3). Figure 3 OTEE: Unless your monitor is purchased as part of a special bundle package, no Option Boards will be in the box or installed...
