4AH: Side by Side 4R (Left Screen smaller vertical expand)
4BH: Side by Side 4L (Left Screen Bigger vertical expand)
In case of Side by Side mode;
20H: Active Left
21H: Active Right
In case of Picture in picture mode;
30H: Active Main
31H: Active Sub
78. SUB PICTURE DETECT SELECT
Function
External control apparatus selects whether to display the sub picture or not,
under picture in picture mode, of plasma monitor.
Transmission Data
DFH 80H 60H 7AH 01H
DATA00 01H : OFF
02H : AUTO
ACK
7FH 60H 80H 7AH 01H
DATA00 01H : OFF
02H : AUTO

79.ZOOM NAVIGATION SELECT

Function
External control apparatus selects digital zoom display of a plasma monitor,
from the alternatives mentioned below;
Transmission Data
DFH 80H 60H 7BH 01H
DATA00
01H : NORMAL
02H : Side By Side(Left Screen smaller)
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
ACK
7FH 60H 80H 7BH 01H
DATA00
01H : NORMAL
DATA00 CKS
DATA00 CKS
DATA00 CKS
DATA00 CKS
69
