02H : Side By Side
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)

80.PICTURE FREEZE SELECT

Function
External control apparatus selects the picture freeze function of a plasma
monitor.
Transmission Data
DFH 80H 60H 7CH 01H
DATA00
01H : OFF(single screen)
02H : Side By Side1(Same Size Screen)
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
07H: Side by Side2 (Same Size Screen vertical expand)
ACK
7FH 60H 80H 7CH 01H
DATA00
01H : OFF(single screen)
02H : Side By Side1
03H : Picture in Picture1(Sub Screen Bottom Left)
04H : Picture in Picture2(Sub Screen Bottom Right)
05H : Picture in Picture3(Sub Screen Top Right)
06H : Picture in Picture4(Sub Screen Top Left)
07H : Side by Side2(Same Size Screen vertical expand)
81. PICTURE FREEZE Command
Function
External control apparatus sets picture freeze or remove picture freeze of a
plasma monitor.
Transmission Data
DFH 80H 60H 7DH 01H
DATA00
01H : FREEZE
02H : FREEZE OFF
DATA00 CKS
DATA00 CKS
DATA00 CKS
70
