Sorting Based on Measured Results (Comparator Function)
Setting Up Sorting Judgment Conditions
Relationship between the limit range designation method and the
setup value
Table 7-1
designation methods when setting up the limit ranges shown in
Figure
Figure 7-1 Example of limit range settings (case 1)
Table 7-1 Lower and upper limit values of limit ranges for
modes)
Keysight E4981B 120 Hz/1 kHz/1 MHz Capacitance Meter
and Table 7-2 compare the setup values between the limit
7-2, respectively.
Absolute mode
Lower Upper
limit
value
BIN1 0.98 nF 0.99 nF
BIN2 0.99 nF 1.01 nF
BIN3 1.01 nF 1.02 nF
Tolerance mode (reference value: 1 nF)
Absolute
Lower
limit limit
value value
–0.02 nF –0.01 nF
–0.01 nF 0.01 nF
0.01 nF 0.02 nF
Figure 7-1
Figure 7-1 (comparison of
Percent
Upper Lower
limit limit
value value
–2%
–1%
1%
and
Upper
limit
value
–1%
1%
2%
