REVOLUTION™ II
SAFE USE & CARE MANUAL
STOP
DO NOT return this product to the store.
IF YOU NEED HELP OR PARTS, CALL THE COLEMAN® HOTLINE:
1 -8 0 0 - 27 5 -4 6 1 7
HOURS: 9AM-7PM EST Mon-Fri, CLOSED Saturday and Sunday
Assemble your barbecue immediately.
Missing or damaged parts must be claimed within 30 days of purchase.
FOR OUTDOOR USE ONLY
BARBECUE SAFETY CHECKLIST
FOR YOUR FAMILY'S SAFETY, PLEASE CHECK THE FOLLOWING:
READ and UNDERSTAND the owner's manual and safety instructions.
DO NOT position operate the barbecue under overhang or unprotected construction, against a wall, near
aluminum siding, windows, or fencing.
CHECK that the regulator nipple is centred into the LP gas cylinder valve. DO NOT cross-thread this connection.
Cross-threading may result in a fire or explosion at the cylinder connection
PERFORM LEAK TEST on all connections as specified in this user manual. Leak checks should be performed
on all new barbecues, even if assembled by an assembler or gas technician. Leak checks should be performed
frequently thereafter.
Before opening the gas supply, ensure the lid is open, control knobs are in "OFF" position, gas is turned off,
and the regulator is attached to cylinder correctly. Then follow the proper lighting procedure as shown in the
manual. Failure to follow these steps may result in low flames or other performance issues.
Beware of HOT SURFACES including lid, lid handle, side tables, and control panel.
Wear protective gloves while barbecuing.
Remove and clean the grease channel, front grease cup, side grease cup, and the heat distribution plates to
avoid grease fires and flare-ups.
Remove and clean the burners to avoid flash fires caused by spider webs and blockages.
Ensure that the barbecue is level.
LAST UPDATE: SEP 27, 2024 - WZ
