LIGHTING INSTRUCTIONS

WARNING
Most Coleman barbecues are sold either Natural Gas or Propane Ready, and are not convertible. Any attempt to convert
a barbecue that does not have a convertible valve system will permanently damage the barbecue's manifold and render it
unusable.
ONLY barbecues bearing the Convertible Valve System logo on the front of the barbecue's control panel are convertible
from propane to natural gas. Visit www.cvsbbq.com to see if your barbecue has this feature.
Lighting main burners
1. Open the lid.
2. Check that all burner control knobs are in the "OFF" position by pushing in
and turning all control knobs clockwise (see image A).
ATTENTION
All burner control knobs must be in the "OFF" position before opening the
LP gas cylinder shut-off valve. If all control knobs are not "OFF" the flow
limiting device in the regulator will be activated, limiting the flow of gas to the
barbecue.
3. SLOWLY, turn LP gas cylinder valve counterclockwise. Wait 30 seconds for
pressure to stabilize.
4. Push in and turn the lighting control knob counterclockwise to the "HI" (
position (see image B).
5. Push the INSTASTART™ IGNITION button (see image C). You should hear a
clicking sound.
6. Check that the burner is lit by looking through the cooking grates or through
the hole in the side of the burner box, located under the side shelf.
7. If the burner lights correctly, push the remaining burners to the "HI" position.
8. If the burner does not light, turn the burner control knob to the "OFF" position
and wait 5 minutes to allow the gas to clear before attempting to light again.
9. For issues lighting with the INSTASTART™ IGNITION button, see the
Troubleshooting section for a resolution, or follow the match lighting
procedure.
WARNING
The burner control knobs must be in the "OFF" position before turning on the LP gas cylinder valve. If left in the "ON"
position, when the LP gas cylinder valve is opened, the "flow limiting device" feature will activate, limiting the flow of gas
from the LP gas cylinder. If this should occur, turn "OFF" the LP gas cylinder valve and burner control knobs and follow the
resetting the flow limiting device instructions.
WARNING
Never stand with your head directly over the barbecue when preparing to light the main burners, to prevent possible bodily
injury.
A
B
)
C
Electronic Ignition Button
