TROUBLESHOOTING
PROBLEM
Burners will not light (with
igniter or match)
Burners will not light with
the igniter, but can match
light (No spark)
Fire at control knob /control
panel- flashback fire
Yellow smokey flames/ gas
odour can be smelled
Flame blows out on LOW
Low heat
Low or incomplete flame
(assuming burners and
venturi tubes are free and
clear of blockages)
Too much heat/ Excessive
flare-ups
• Positive connection has not been made between the LP gas cylinder and the regulator.
• Low or out of propane.
• Gas supply valve is turned off.
• Burners are not properly seated over valve orifices.
• Flow limiting device in regulator has been activated. Follow reset instructions on page 8.
• Replace the ignition module battery with the negative side facing outward.
• Check and secure loose ignition button lead wires on the control panel by firmly pushing them
in until they click.
• Ensure all wires at the electronic ignition module inside the cabinet are securely pushed in.
• Contact customer support for a replacement if the electronic ignition module is fault.
• If flames are forced back towards the user, the burner or burner tubes may be blocked. Remove
and clean the burners following the steps on page 19.
• Ensure the burner is properly seated over the gas jet; the gas valve must fit inside the burner
venturi. Disassemble and reassemble the burner assembly as needed.
• If the burner or burner venturi is obstructed (possibly by spider webs or debris), remove and
clean the burners following the steps on page 19 of the manual.
• If the flow limiting device in the regulator activates, it may be due to a leak or improper lighting.
Conduct a leak test (see page 9) and reset the regulator (see page 8).
• Ensure there is sufficient propane in the LP gas cylinder.
• In high wind conditions, adjust your barbecue to shield it from wind.
• Check if the burner is properly seated on the gas jet. The gas valve must fit inside the burner
venturi. Disassemble the burner and correct the assembly if necessary.
• The flow limiting device in the regulator has been tripped, restricting gas flow to the burners.
Perform a regulator reset (see page 8) and ensure proper lighting procedure (see pages 12-13)
to prevent recurrence.
• Verify if the issue affects only one burner. If so, the burner and/or burner tubes may be blocked.
Remove and clean the burners following the steps on page 19.
• Inspect for any bends or kinks in the fuel hose.
• During colder temperatures, extend the preheating period to ensure optimal performance.
• Flow limiting device in regulator has been activated due to a leak or improper lighting. Perform
a leak test (see page 9) and perform a regulator reset (see page 8).
• Excessive grease and build-up on heat tents, in grease tray and within burner box. Follow
cleaning steps on pages 19-22.
• Using the "HI" temperature setting. Only use the "HI" setting for preheat and searing. Always
adjust temperature to avoid too much heat.
• Covering more than 70% of the cooking surface may cause overheating.
• Excessive fat on meat. Always cut fat where possible to limit excess grease drippings.
IDENTIFYING THE CAUSE
