Coleman REVOLUTION II Safe Use & Care Manual page 7

INSTALLING THE LP GAS CYLINDER
Hose and regulator
Your barbecue is equipped with a Type 1 connection device with the following features:
1. The system will not allow gas flow from the cylinder until a positive connection to valve has been made. NOTE: The
cylinder valve and all control knobs must be turned OFF before any connection is made or removed.
2. A regulator flow limiting device, when activated, restricts the flow of gas to 10 cubic feet per hour. If the flow limiting
device is activated, perform Regulator Reset Procedure.
NOTE
: If you are experiencing performance issues such a low heat, low flame, or difficulty lighting, you have likely tripped
your regulators flow limiting feature. Follow steps for regulator reset, on page 8.
3. A thermal element built into the regulator supply hose will shut the flow of gas between
240—300 °F (115.5—148.8 °C).
Connecting hose and regulator
ATTENTION
Visually inspect hose prior to each use for damage, excess wear, or deterioration. If found, replace hose before using your
barbecue. Only the manufacturer's supplied replacement should be used.
1. Inspect LP gas cylinder valve rubber seal for cracks, wear or deterioration
prior to use. A damaged rubber seal can cause a gas leak, possibly resulting
in an explosion, fire or severe bodily harm. Do not use a LP gas cylinder with a
damaged rubber seal.
2. Check that the barbecue's burner control knobs are "OFF".
3. Check that the cylinder valve is closed by turning knob clockwise.
4. Position the LP gas cylinder into the barbecue cabinet and secure with the LP
gas cylinder screw.
5. Remove the protective plastic cap from cylinder valve.
6. Check that the hose does not contain kinks, and ensure that the supply hose does not come in contact with any sharp
edges.
WARNING
Ensure that the supply hose does not come in contact with the heat shield above.
7. Connect the Type 1 regulator coupling to the cylinder valve, turning clockwise. Hold the regulator in a straight line with
the LP gas cylinder when connecting. Take care not to cross thread. Hand-tighten only.
8. Leak check all fittings before lighting your barbecue. See section on "Leak Testing" in
this manual.
NOTE
: To remove the regulator from the LP gas cylinder, turn off the LP gas cylinder valve and rotate the large coupling nut
counterclockwise.
Inspect Rubber Seal (see page 6)
7
