reVOLUtiOn
TM
4
Burner
ASSEMBLY MANUAL
85-3120-4 (G53203) Propane
85-3121-2 (G53204) Natural Gas
Limited 5-Year WarrantY
Read and save manual for future reference.
Assemble your grill immediately. Missing or damaged parts
should be claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-800-275-4617.
www.colemanbbqs.com
Manual Revision #: 12092015 AT

Advertisement

loading
Need help?

Need help?

Do you have a question about the Revolution 85-3121-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Coleman Revolution 85-3121-2

Summary of Contents for Coleman Revolution 85-3121-2

  • Page 1 reVOLUtiOn Burner ASSEMBLY MANUAL 85-3120-4 (G53203) Propane 85-3121-2 (G53204) Natural Gas Limited 5-Year WarrantY Read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1-800-275-4617.
  • Page 2 H e aV Y a r t i C L e n e e d S 2 t O L i F t tHiS manUaL mUSt remain WitH tHe PrOdUCt at aLL timeS To OrDer non-warranty replacement parts or accessories, or to register your warranty, please visit us on the web at www.colemanbbqs.com CaUtiOn...

  • Page 3: Hardware Pack

    HARDWARE PACK no. Description Part number Qty. tOOLS needed FOr aSSemBLY 1/4"-20UNCx38 Screw 20120-13038-250 • #2 Phillips screwdriver (long and short) 1/4"-20UNCx16 Screw 20120-13016-250 NO.10-24UNCX35 Screw 20124-10035-250 • 1/4” Slotted screwdriver (long and short) NO.10-24UNCX13 Screw 20124-10013-250 • Adjustable wrench NO.8-32UNCX18 Screw 20132-08018-250 •...
  • Page 4 PARTS LIST (PROPANE) FOR 85-3120-4 (G53203) Item no. Qty. Description Part no. Item no. Qty. Description Part no. Top Lid Assembly G532-2500-02 Sear Stove Side Shelf, Left G532-0900-01 Lid Handle G532-2500-02 Side Shelf Fascia, Left G532-4300-01 Thermometer G532-0007-01 Side Shelf Table Rear Brace, G532-1300-01 Left Thermometer Bezel...
  • Page 5 EXPLODED DIAGRAM (PROPANE) FOR 85-3120-4 (G53203) extras Assembly Safe Use Manual & Care Hardware Manual Pack...
  • Page 6 PARTS LIST (NATURAL GAS) FOR 85-3121-2 (G53204) Item no. Qty. Description Part no. Item no. Qty. Description Part no. Top Lid Assembly G532-2500-02 Sear Stove Side Shelf, Left G532-0900-01 Lid Handle G532-2500-02 Side Shelf Fascia, Left G532-4300-01 Thermometer G532-0007-01 Side Shelf Table Rear Brace, G532-1300-01 Left Thermometer Bezel...
  • Page 7 EXPLODED DIAGRAM (NATURAL GAS) FOR 85-3121-2 (G53204) extras Assembly Safe Use Manual & Care Hardware Manual Pack...
  • Page 8 ASSEMBL Y INSTRUCTIONS 6 1 4...
  • Page 9 ASSEMBL Y INSTRUCTIONS...
  • Page 10 ASSEMBL Y INSTRUCTIONS...
  • Page 11 ASSEMBL Y INSTRUCTIONS...
  • Page 12 ASSEMBL Y INSTRUCTIONS...
  • Page 13 ASSEMBL Y INSTRUCTIONS...
  • Page 14 ASSEMBL Y INSTRUCTIONS WarninG: WatCH YOUr HandS!
  • Page 15 ASSEMBL Y INSTRUCTIONS...
  • Page 16 ASSEMBL Y INSTRUCTIONS...
  • Page 17 ASSEMBL Y INSTRUCTIONS...
  • Page 18 ASSEMBL Y INSTRUCTIONS...
  • Page 19 ASSEMBL Y INSTRUCTIONS tiP: Ensure that the rubber side of the rubberized washer makes contact with the burner box.
  • Page 20 ASSEMBL Y INSTRUCTIONS...
  • Page 21 ASSEMBL Y INSTRUCTIONS...
  • Page 22 ASSEMBL Y INSTRUCTIONS 6 1 1...
  • Page 23 ASSEMBL Y INSTRUCTIONS 6 1 3...
  • Page 24 ASSEMBL Y INSTRUCTIONS...
  • Page 25 ASSEMBL Y INSTRUCTIONS electronic ignition assembly The electrode sets for main burner (CF), sear stove (DF) and instastart buttons (CE3) are found under the control panel, attached to the manifold (CA). Insert them into the electronic ignition (CE1). (CE3) InstaStart Button Sear Stove...
  • Page 26 ASSEMBL Y INSTRUCTIONS...
  • Page 27 ASSEMBL Y INSTRUCTIONS...
  • Page 28 ASSEMBL Y INSTRUCTIONS...
  • Page 29 ASSEMBL Y INSTRUCTIONS...
  • Page 30 ASSEMBL Y INSTRUCTIONS...
  • Page 31 ASSEMBL Y INSTRUCTIONS...
  • Page 32 ASSEMBL Y INSTRUCTIONS...
  • Page 33 ASSEMBL Y INSTRUCTIONS attentiOn: StaCK GrateS BeFOre POSitiOninG.
  • Page 34 ASSEMBL Y INSTRUCTIONS...

  • Page 35: Model Only

    ASSEMBL Y INSTRUCTIONS FOr PrOPane mOdeL OnLY attentiOn: dO nOt StOre eXtra PrOPane tanK WitHin BBQ Cart.
  • Page 36 ASSEMBL Y INSTRUCTIONS FOr natUraL GaS mOdeL OnLY attentiOn: Your BBQs natural gas hose comes with a 3/8” connection. For 1/2” home connections, an adapter may be required. Contact your natural gas supplier to purchase the necessary part. DO nOT uSe natural Gas Home Supply Quick...

  • Page 37: Also Available

    ACCESSORIES aLSO aVaiLaBLe Visit Canadian tire: Product # 85-1994 Coleman® rotisserie Kit with meat Probe...
  • Page 38 ADDITIONAL WARNINGS You have now completed the Assembly of your COLEMAN® REVOLUTION™ BARBECUE. neXt StePS: 1. Position your BARBECUE 2. Read SAFE USE & CARE MANUAL 3. Perform Grill Safety Check-list WarninG: WarninG HOt SUrFaCeS: FOR YOUR FAMILIES SAFETY, DO NOT ATTEMPT TO LIGHT...
  • Page 40 Join the conversation facebook.com/colemangrills twitter.com/colemangrills Manufactured by Winners Products Engineering Ltd. Coleman are registered trademarks of ® The Coleman Company, Inc. used under license. ©2016 The Coleman Company, Inc. www.colemanbbqs.com...

This manual is also suitable for:

Revolution 85-3120-4
