Installation Guide | iC7 Series Liquid-cooled LC Filter OF7Z1
Ø18
150
(Ø0.71)
(5.91)
6 x Ø12.5
(Ø0.49)
115
(4.53)
22
115
(0.87)
(4.53)
261
(10.28)
18
(0.71)
397
(15.63)
433
(17.05)
Figure 6: Dimensions of the LC Filter Size 12, in mm (in)
3 Cooling Requirements
Safety in Liquid-cooling
3.1
POISONOUS COOLANTS
Glycols and inhibitors are poisonous. If touched or consumed, they can cause injury.
Prevent the coolant from getting into the eyes. Do not drink the coolant.
l
HOT COOLANT
Hot coolant can cause burns.
Avoid contact with the hot coolant.
l
PRESSURIZED COOLING SYSTEM
Sudden release of pressure from the cooling system can cause injury.
Be careful when operating the cooling system.
l
