Table 3: Wiring of the AuxBus Terminals
Pin
3
4
5
1
2
3
Figure 16: The Ready AuxBus Cable
1
Terminals
3
Shield removed
4.10
AuxBus Connections
For the drive to be able to protect the filters, AuxBus must be connected.
For more information about AuxBus, see the iC7 Series Liquid-cooled System Modules Design Guide.
Procedure
1.
To access the AuxBus temperature measurement board, remove the cover.
Danfoss Drives Oy © 2024.11
(continued)
Wire color
Green
Yellow
Grey
2
2
NOTICE
Signal
CAN_H
CAN_L
+24 V
1
Wires
AN447722908366en-000201 / 172K1110B |
Electrical Installation
13
