Print data
In the advanced menu, users can select the Print Data item and select the data
logging mode. Data of oscilloscope interface will be recorded to U disk.
Print data mode:
⚫
⚫
⚫
⚫
9.3 Harmonic measurement
IT7900P series source can display harmonic parameters in the list or bar chart
form to make the analysis of test result clear.
9.3.1 Harmonic Measurement
Press
harmonic measurement will appear.
⚫
The trigger source is used for generating trigger conditions. The user can
select the trigger source in the input signal of the input unit.
Trigger slope
The slope refers to the change of the signal from low level to high level
(rising edge) or from high level to low level (falling edge). The slope used as
a trigger condition is referred to as the trigger slope.
Trigger level
The trigger level refers to the level which the trigger slope passes through.
If the signal of the trigger source passes through the set trigger level
according to the specified trigger slope, triggering occurs. When the soft key
[Function] is pressed and "Trig-Level" is selected, you can rotate the knob
to adjust the trigger level. In this case, the trigger level can be changed by
rotating the knob and you can observe trigger level changes on the screen.
Off: turn off the print data function.
Post: The recorded data is consistent with the data displayed on the
oscilloscope interface
Raw: The recorded data is original data, The default data sampling interval
is 10us
Both: Post and Raw, record two data file.
key on the front panel, and the following initial interface of
Harmonic bar chart screen
