1.2 Models and Options
Model
IT7905P-350-30U
IT7906P-350-90
IT7908P-350-90
IT7909P-350-90
IT7912P-350-90
IT7915P-350-90
IT7930P-350-180
IT7945P-350-270
IT7960P-350-360
IT7975P-350-450
IT7990P-350-540
IT79105P-350-630
IT79120P-350-720
IT79135P-350-810
IT79150P-350-900
IT79165P-350-990
1.3 Optional accessories
The IT7900P series supports the following optional accessories (sold
separately), the details are as below:
The interface expansion slot provided on the rear panel of the IT7900P series
instrument allows users to flexibly expand according to their needs. Different
interface cards can be selected to achieve different functions.
The following optional accessories from ITECH are sold separately. Users need
to purchase separately.
voltage waveform and the power factor is as close to 1 as possible
Supporting unloading angle control, 0-359° adjustable
mode, current harmonic simulation in load mode, fundamental wave≤60Hz
is restricted by the crest factor
Power
5kVA
6kVA
8kVA
9kVA
12kVA
15kVA
30kVA
45kVA
60kVA
75kVA
90kVA
105kVA 350V
120kVA 350V
135kVA 350V
150kVA 350V
165kVA 350V
Note
Naming rules for this series of model are as follows: IT79XXX-YYY-ZZZ,
wherein, XXX means rated power, YYY means rated voltage, and ZZZ
means rated current. Take IT7915P-350-90 for an example, the rated
power is 15kVA, rated voltage is 350V and rated current is 90A. In
addition, ATE indicates that this model is a system model without an
operator panel.
