Remote sense
On/Off phase
Measurement
Power Unit Setting
Load mode Menu:
Device operation
mode
Phase mode
Couple mode
Load
Load phase loss
U ratio
I ratio
Set the sense function state.
Mode
On-mode
Off-mode
Set the measurement speed
Lowest (1Hz)
Lower (1000ms)
Slow (500ms)
Medium (300ms)
Fast (150ms)
Filter
Unit of power, can be set to KW/kVA/KVar or W/VA/Var.
Set the instrument mode
Volt Source: voltage source load
Load: load mode
Set the AC input mode
1-Phase
3-Phase
Reverse
Set input mode
AC
DC
Loss phase setting (only for three phase mode)
A phase
B phase
C phase
Copyright ©ITECH Electronic Co., Ltd.
System-Related Functions
The external program ratio of
voltage.
The external program ration of
current.
On: Enable the remote sense
Measurement
Off: disable the sense function
⚫ Output on phase control
⚫ Phase: setting the phase
⚫ Imm: immediately
⚫ Slope: Controlled according to
the set slope
⚫ Output off phase control
⚫ Phase: setting the phase
⚫ Imm: immediately
Slope: Controlled according to
⚫
the set slope
Lowest mode, measuring every 2s
Lower mode, measuring every
1000ms
Slow mode, measuring every
500ms
Medium mode, measuring every
300ms
Fast mode, measuring every
150ms
Whether to turn on the filter during
measurement.
Single phase
Three phase
Reverse phase
AC mode
DC mode
Loss phase setting (only for three
phase mode)
Disable: not loss
Enable: B phase loss (only for
Wye-connection.)
Disable: not loss
