Jasic EVO 2.0 Operator's Manual page 27

CONTROL PANEL - FUNCTIONS
Wired (Foot pedal / hand-held) Remote Control
A 9 pin remote control socket is 昀椀琀琀ed as standard to the front panel of the machine, see
page 28 for op琀椀onal remote controls)
1) Before welding, press the remote-control func琀椀on
control func琀椀on.
2) The indicator will be lit indica琀椀ng that the remote-control func琀椀on is enabled.
If the remote controller is connected, the remote control device controls the welding current.
If no remote controller is connected then the welding current is controlled by the panel control dial.
3) If the indicator is not lit, this indicates that the remote-control func琀椀on is not ac琀椀ve and welding
current is controlled by the front panel control dial.
Wireless Remote Control (op琀椀onal)
(Wireless remote control interface is op琀椀onal, see page 27 for remote op琀椀ons)
1) Wireless pairing connec琀椀on
Before welding, press and hold the panel remote control func琀椀on bu琀琀on
the pairing bu琀琀on
wireless remote control pairing.
During pairing, the blue indicator of wireless receiver module
indicator of remote control mode is on .
At the same 琀椀me the blue indicator of wireless receiver module
display window displays "OK".
A昀琀er successful pairing, the welding current can be adjusted by "+" or "-" bu琀琀ons on the wireless
remote controller.
The range of current is from the machines minimum to the maximum current value which was previously
displayed as preset current on the panel.
2) Disconnec琀椀ng the wireless connec琀椀on
A昀琀er the remote controller is successfully paired, press the remote control func琀椀on bu琀琀on
panel or the pairing bu琀琀on
connec琀椀on of the remote controller will be disconnected.
A昀琀er disconnec琀椀ng the display window of the welder displays the character "FAL", and the green
indicator of the wireless receiver module
Serial Number Display
number from the display.
If you do not perform any welding opera琀椀on or touch any bu琀琀on on the control panel, the
serial number will clear automa琀椀cally from the display a昀琀er 20 seconds.
of the wireless remote controller at the same 琀椀me, hold for 2 seconds to perform
of the wireless remote controller for 2 seconds, and the wireless
When the machine is in it's idle state (before welding), press and hold both the
welding mode bu琀琀on and the parameter adjustment dial bu琀琀on (as shown le昀琀)
for 3 seconds to display the machines serial number.
Rota琀椀ng the encoder will allow the operator to scroll though to see
the full serial number from the display. Pressing any key will clear the serial
bu琀琀on to enable the remote
昀氀ashes, a昀琀er successful pairing, the
will be constantly on.
27
and
will be constant on and the welder
on the
