LC-30(C0S1)
WATER COOLER
Copyright©2022 Shenzhen JASIC Technology Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Jasic LC-30

  • Page 1 LC-30(C0S1) WATER COOLER Copyright©2022 Shenzhen JASIC Technology Co., Ltd.
  • Page 2 JASIC dealer or visit JASIC website at www.jasictech.com. Disclaimer Shenzhen JASIC Technology Co., Ltd. solemnly promises that this product is manufactured according to relevant domestic and international standards, and that this product conforms to EN60974-1 International Safety Standard. Patents protect the relevant design scheme and manufacturing technology adopted in this product.
  • Page 3: Table Of Contents

    Contents 1. Safety Precautions..........................4 2. Product Overview..........................5 3. Performance Features........................5 4.Technical Parameters........................5 5. Installation and Operating Instructions..................6 6. Precautions............................8 7. Fault and Maintenance........................8 Appendix A Packaging, Transportation and Storage..............11 Appendix B Wiring Diagram of Complete Machine..............12 Page 3...
  • Page 4: Safety Precautions

    1. Safety Precautions Electric Shock Install the grounding device according to the applicable standards. Do not touch live parts when the skin is exposed, wearing wet gloves or wearing wet clothes. Make sure you are insulated from the ground and the weldment. Cover the cover plate before power-on;...
  • Page 5: Product Overview

    MIG/TIG precision welding equipment. This product has good cooling effect and is energy-saving, environmental and pollution-free. 4.Technical Parameters Note: Some parameters are acquired under experimental conditions. Technical Parameters Units LC-30 COS1 Rated input voltage Single-phase AC115-230V±15% 50Hz AC115@92w Rated input power AC230@115W...
  • Page 6: Installation And Operating Instructions

    5. Installation and Operating Instructions Fig. 1 Installation and connection Operational Instructions ●Connect the welding gun reliably (connect the red to the return pipe and the blue to the outlet pipe), uncover the water tank and add coolant (please add anti-freezing solution if the temperature is lower than 5℃).
  • Page 7 Front panel description: 1 Return pipe (red) 2 Outlet pipe (blue) 3 Overheat warning light 4 Flow warning light 5 Power light 6 Water filling nozzle of kettle 7 Drainage port Description of rear panel: 1 Power line Water level description: The lowest water level should be no lower than the indication line in work;...
  • Page 8: Precautions

    6. Precautions 1. Please ensure the power grid is consistent with the machine label before use, since connection of incorrect power grid may damage the machine. 2. There should be no obstacles in 0.3m of the vent of the water tank. Ensure good ventilation of the machine.
  • Page 9 Fault Phenomenon and Solution: Symptom Corrective Action The power light does not light 1 Inspect whether the power line is connected correctly. up, the water pump does not 2 Inspect and confirm that input cables are connected to work, water does not flow in the power supply.
  • Page 10 1 Inspect whether the operating power exceeds the cooling power. Please do not use operating power exceeding the cooling power. If the water temperature is too high, the machine cannot be reused before the The power light lights up, the temperature falls and the temperature warning light lights water pump works properly, off.
  • Page 11: Appendix A Packaging, Transportation And Storage

    Appendix A Packaging, Transportation and Storage A.1 Packaging This product is packaged individually. A.2 Transportation In the process of handling equipment, it shall be handled with care, and it shall not be severely impacted. Moisture and rain shall be prevented during transportation. A.3 Storage Storage temperature: -20℃-60℃.
  • Page 12: Appendix B Wiring Diagram Of Complete Machine

    Appendix B Wiring Diagram of Complete Machine Light AC115V-AC230V/1~50Hz PCBA Thermal Protection Flow Switch Page 12...
  • Page 13 Page 13...
