FVC UN0307B Installation Manual

Hanging solo bed with legs - adult
Hide thumbs

Advertisement

Quick Links

Download this manual
H ANGI NG SO LO BED W I T H L EGS - AD U LT
UN0 30 7B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
MEASURING TAPE
+
RATCHET
+
9/16" WRENCH OR SOCKET
+
5/8" WRENCH OR SOCKET
+
5/32" ALLEN WRENCH
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 1 HOUR
Additional help is suggested for a few of the install
steps.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that all
parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the UN0307B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FVC UN0307B

Summary of Contents for FVC UN0307B

  • Page 1 INSTALLATION GUIDE H ANGI NG SO LO BED W I T H L EGS - AD U LT UN0 30 7B TOOLS REQUIRED (NOT INCLUDED) MEASURING TAPE RATCHET 9/16” WRENCH OR SOCKET 5/8” WRENCH OR SOCKET 5/32” ALLEN WRENCH INSTALL INFO TIME TO INSTALL THIS PRODUCT: 1 HOUR Additional help is suggested for a few of the install steps.

  • Page 2: Before You Start

    BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage.

  • Page 3: Package Contents

    PACKAGE CONTENTS SOLO BED PANEL HINGE ASSEMBLY LEFT BED LEG RIGHT BED LEG QTY: 1 QTY: 2 QTY: 1 QTY: 1 CAM STRAP WITH L-TRACK ANCHOR QTY: 2 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
  • Page 4 HARDWARE 1/4-20 X 0.75 FLANGED 3/8-16 X 1 SQUARE NECK L-TRACK STUD 1/4 SCREW FLAT WASHER HEX HEAD SCREW CARRIAGE BOLT QTY: 4 QTY: 4 QTY: 2 QTY: 4 1/4-20 X 0.75 FLANGED 3/8 SCREW FLAT WASHER 3/8-16 NYLON LOCKNUT BUTTON HEAD HEX SCREW QTY: 2 QTY: 2...
  • Page 5 STEP | 01 LAYOUT AND INSTALL PREP 1.1 Dimensions of Solo Bed: The Hanging Solo Bed is designed for installation in vans equipped with L-Track and FVC Bed Brackets. Refer to FIG 1 and 2 for relevant dimensions to assist with the layout and installation of your new Solo Bed.
  • Page 6 5/8” WRENCH TOOLS REQUIRED FOR THIS STEP: STEP | 01 SOLO BED ASSEMBLY For L-Track Install: 1.1a Determine Install Height: Dry fit Hinge Assemblies to your L-Track and determine the desired install height of your Solo Bed (FIG 3a). 1.2a Attach Hinge Assemblies to L-Track: Attach the Hinge Assemblies to the desired height along your L-Track using the 5 INCHES included L-Track Studs (FIG 4a).
  • Page 7 7/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: STEP | 01 SOLO BED ASSEMBLY For Bed Bracket Install: 1.1b Determine Install Height: Dry fit Hinge Assemblies to your Bed Brackets and determine the desired install height of your Solo Bed (FIG 3b). 1.2b Attach Hinge Assemblies to Bed Brackets: Attach the Hinge Assemblies to the desired height along your Bed Brackets using the threaded holes and included 1/4-20 x 0.75...
  • Page 8 5/32” ALLEN WRENCH TOOLS REQUIRED FOR THIS STEP: STEP | 02 SOLO BED ASSEMBLY 2.1 Attach Legs to Bed: Attach both Legs to Solo Bed using (4ea) 1/4-20 x 0.5 Flanged Button Head Screws in the predrilled locations shown in FIG 5+6. NOTE - The Legs are directional.
  • Page 9 9/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: STEP | 03 SOLO BED INSTALL 3.1 Attach Bed Panel to Hinges: With help, attach Solo Bed Panel to Hinges using (1ea) 3/8-16 x 1 Square Neck Carriage Bolts, 3/8” Flat Washers and Nylon Locknuts (FIG 9) in the locations shown in FIG 9.
  • Page 10 TOOLS REQUIRED FOR THIS STEP: 5/32” ALLEN WRENCH STEP | 03 SOLO BED INSTALL 3.2 Adjust Leg Height: Deploy the Bed Legs and check the leveling. If adjustment is needed, remove the 1/4-20 X 0.75 Flanged Button Head Hex Screws, Flat Washers, And Nylon 13.4 Locknuts (FIG 10).
  • Page 11 FVC (and see) from you! Head to the products and following along and we will make it right. FVC is product page and click “Leave a company of van and outdoor with your adventures. Tag us Review.”...
