H ANGI NG SO LO BED - A D ULT
UN0 30 3B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
MEASURING TAPE
+
RATCHET
+
9/16" WRENCH OR SOCKET
+
5/8" WRENCH OR SOCKET
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 1 HOUR
Additional help is suggested for a few of the install
steps.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that all
parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for FVC UN0303B
Summary of Contents for FVC UN0303B
- Page 1 INSTALLATION GUIDE H ANGI NG SO LO BED - A D ULT UN0 30 3B TOOLS REQUIRED (NOT INCLUDED) MEASURING TAPE RATCHET 9/16” WRENCH OR SOCKET 5/8” WRENCH OR SOCKET INSTALL INFO TIME TO INSTALL THIS PRODUCT: 1 HOUR Additional help is suggested for a few of the install steps.
-
Page 2: Before You Start
BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage. -
Page 3: Package Contents
PACKAGE CONTENTS QTY: 1 QTY: 1 QTY: 1 QTY: 1 ADULT-SIZE SOLO SOLO BED HINGE CAM STRAP W/ BED PANEL ASSEMBLY L-TRACK ANCHORS QTY: 1 QTY: 2 QTY: 2 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6... - Page 4 HARDWARE 1/4-20 X 0.75 FLANGED 3/8-16 X 1 SQUARE NECK L-TRACK STUD 1/4 SCREW FLAT WASHER HEX HEAD SCREW CARRIAGE BOLT QTY: 4 QTY: 4 QTY: 2 QTY: 4 3/8 SCREW FLAT WASHER 3/8-16 NYLON LOCKNUT QTY: 2 QTY: 2 F L AT L I N E VA N C O •...
- Page 5 STEP | 01 LAYOUT AND INSTALL PREP 1.1 Dimensions of Solo Bed: The Hanging Solo Bed is designed for installation in vans equipped with L-Track and FVC Bed Brackets. Refer to FIG 1 and 2 for relevant dimensions to assist with the layout and installation of your new Solo Bed.
- Page 6 5/8” WRENCH TOOLS REQUIRED FOR THIS STEP: STEP | 01 SOLO BED ASSEMBLY For L-Track Install: 1.1a Determine Install Height: Dry fit Hinge Assemblies to your L-Track and determine the desired install height of your Solo Bed (FIG 3a). 1.2a Attach Hinge Assemblies to L-Track: Attach the Hinge Assemblies to the desired height along your L-Track using the 5 INCHES included L-Track Studs (FIG 4a).
- Page 7 7/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: STEP | 01 SOLO BED ASSEMBLY For Bed Bracket Install: 1.1b Determine Install Height: Dry fit Hinge Assemblies to your Bed Brackets and determine the desired install height of your Solo Bed (FIG 3b). 1.2b Attach Hinge Assemblies to Bed Brackets: Attach the Hinge Assemblies to the desired height along your Bed Brackets using the threaded holes and included 1/4-20 x 0.75...
- Page 8 9/16” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: STEP | 03 SOLO BED INSTALL 3.1 Attach Bed Panel to Hinges: With help, attach Solo Bed Panel to Hinges using (1ea) 3/8-16 x 1 Square Neck Carriage Bolts, 3/8” Flat Washers and Nylon Locknuts (FIG 5+6) in the locations shown in FIG 7.
- Page 9 L-Track Anchor (FIG 11), but you could use whatever is most convenient for you. NOTE - If you aren’t mounting the Solo Bed to FVC Bed Brackets only, you may need a different strap solution (such as S-Hooks). Otherwise you can find small L-Track sections online to use in accordance with the FVC Bed Brackets.
- Page 10 FVC (and see) from you! Head to the products and following along and we will make it right. FVC is product page and click “Leave a company of van and outdoor with your adventures. Tag us Review.”...
