UNI VE RS AL F O LD DOW N TAB LE
UN1 10 9B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
7/16" WRENCH OR SOCKET
+
RATCHET
+
5/32" ALLEN WRENCH
+
MEASURING TAPE
+
10MM WRENCH
+
MARKER
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 30-45 MINUTES
Additional help is suggested for a few of the install steps.
Compatible with all FVC Rear Door Platforms.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that
all parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for FVC UN1109B
Summary of Contents for FVC UN1109B
- Page 1 INSTALL INFO TIME TO INSTALL THIS PRODUCT: 30-45 MINUTES Additional help is suggested for a few of the install steps. Compatible with all FVC Rear Door Platforms. BEFORE YOU START Please inspect the product and packaging upon delivery to ensure there are no issues and that all parts and hardware are accounted for.
- Page 2 BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage.
- Page 3 PACKAGE CONTENTS FOLD DOWN TABLE QTY: 1 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
- Page 4 HARDWARE 1/4 OVERSIZED FLAT 1/4-20 X0.75 FLANGED 1/4-20 NYLON INSERT 1/4 SCREW FLAT WASHER WASHER BUTTON HEAD SCREW LOCKNUT QTY: 4 QTY: 4 QTY: 4 QTY: 4 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
- Page 5 FIG 1 for the overall dimensions and distances between the OVERALL DIMS mounting points. 1.2 If you are using a product other than an FVC Rear Door 18” Product, mark the back of the table to match your available mounting points and drill out (4) 1/4” holes accordingly.
- Page 6 TOOLS REQUIRED FOR THIS STEP: STEP | 02 FOLD DOWN TABLE INSTALL 2.1 Use the Push Button to open the Fold Down Table to access the mounting holes (FIG 2). F I G 2 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
- Page 7 TOOLS REQUIRED FOR THIS STEP: 5/32” ALLEN WRENCH RATCHET 7/16” WRENCH OR SOCKET STEP | 02 FOLD DOWN TABLE INSTALL 2.2 Insert (1ea) 1/4-20 x 0.75” Flanged Hex Head Screws to the upper mounting holes (FIG 3). 2.3 With help, lift and align top holes with hardware to the desired mounting location.
- Page 8 TOOLS REQUIRED FOR THIS STEP: 10MM WRENCH STEP | 03 FOLD DOWN TABLE ADJUST BUTTON LATCH 3.1 Using two 10MM Wrenches, loosen the Ball Stud and adjust as needed. Tighten Jam Nuts and verify adjustment by closing the door. Door should click into place easily, release smoothly, and achieve seal compression.
