Installation Guide | Advanced Active Filter AAF 007
Instructions
1
Safety and Installation Awareness
1.1
Both an installation guide and a safety guide are provided with the filter. Before starting installation, get familiarized with all safety
guidelines and precautions in the safety guide.
The Advanced Active Filter AAF 007 module is not intended for service and repair outside the factory. Malfunctioning units must be
replaced and returned to the factory.
Intended Use
1.2
The Advanced Active Filter AAF 007 is intended to be used in electrical installations to improve power quality. To achieve an improved
power quality, the filter injects currents in counter-phase to mitigate distortions on the grid.
Required Tools
1.3
Tape measure
l
Slotted screwdrivers (SL1/SL2)
l
PH1, PH2 screwdrivers
l
Wrench with extender and 10 mm (for wall mounting)
l
Cable strip
l
Wire crimper for mains cable
l
Electrical and Mechanical Ratings
1.4
Enclosure AAF01
Current 35 A
Mains supply 3x380–277Y/480 / 50–
60 Hz
Mains type TN, TT, IT (non-corner
grounded)
Current 0–35 A
Ambient Minimum -10 °C (14 °F)
temperature
Maximum 50 °C (122 °F)
Derating above 40 °C
(104 °F)=-3%/K (up to
50 °C (122 °F))
P 556 W
loss
Weight 16 kg (35.3 lb)
Dimensions 510x106x360 mm
(HxWxD) (20.1x4.2x14.2 in)
SCCR 100 kA
Danfoss A/S © 2024.06
55 A
3x380–277Y/480 / 50–
60 Hz
TN, TT, IT (non-corner
grounded)
0–55 A
Minimum -10 °C (14 °F)
Maximum 50 °C (122 °F)
Derating above 40 °C
(104 °F)=-3%/K (up to
50 °C (122 °F))
833 W
17 kg (37.5 lb)
510x106x360 mm
(20.1x4.2x14.2 in)
100 kA
AAF02
100 A
3x380–277Y/480 / 50–
60 Hz
TN, TT, IT (non-corner
grounded)
0–100 A
Minimum -10 °C (14 °F)
Maximum 50 °C (122 °F)
Derating above 40 °C
(104 °F)=-3%/K
(up to 50 °C (122 °F))
1283 W
31 kg (68.3 lb)
755 x 61x 482 mm
(29.72x2.4x18.98 in)
100 kA
AN430846972679en-000202 / 130R1283 |
Instructions
150 A
3x380–277Y/480 / 50–
60 Hz
TN, TT, IT (non-corner
grounded)
0–150 A
Minimum -10 °C (14 °F)
Maximum 50 °C (122 °F)
Derating above 40 °C
(104 °F)=-3%/K
(up to 50 °C (122 °F))
2120 W
33 kg (72.7 lb)
755 x 61x 482 mm
(29.72x2.4x18.98 in)
100 kA
