Installation Guide | Advanced Active Filter AAF 007
Table 1: Cable and Fuse Specifications
Enclosure AAF01
Current 35 A module
2
Control cables 1 mm (17 AWG)
cross-section
Torque 0.8 Nm (7.1 in-lb)
Internal semi- Sinofuse RS308-HB-4G60A
conductor 750VDC
fuse
Danfoss A/S © 2024.06
(continued)
55 A module
2
1 mm (17 AWG)
0.8 Nm (7.1 in-lb)
Sinofuse RS308-
HB-4G100A 750VDC
AAF02
100 A module
2
1 mm (17 AWG)
0.8 Nm (7.1 in-lb)
Sinofuse RS308-
HB-4G160A 750VDC
AN430846972679en-000202 / 130R1283 |
Instructions
150 A module
2
1 mm (17 AWG)
0.8 Nm (7.1 in-lb)
Sinofuse RS308-
HB-4G200A 750VDC
