EGR ROLLTRAC RT038812E Installation Instructions Manual page 6

ANTI RUST
HOLES FOR FRONT DRAIN TUBES
RHS & LHS
ATTENTION
Ensure that the diameter
of the hole does not exceed
Larger hole size will lead to water ingress
INSTALL FRONT DRAIN TUBES TO BED
1
14
3 Mark the position of the front drain tubes holes in the bed front panel and drill with
repeat on the RHS.
Fit front drain tubes (14).
ANTI RUST
HOLES FOR REAR DRAIN TUBES
RHS & LHS
ATTENTION
Ensure that the diameter
of the hole does not exceed
Larger hole size will lead to water ingress
4
Mark the position of the rear drain tubes holes in the bed rear panel and drill with
repeat on the RHS.
RT0046
Ø38mm (11/2").
into the bed
2
Clean all burrs and coat the exposed metal with a suitable rust preventative (not supplied).
Ø29mm (11/8")
into the bed
Clean all burrs and coat the exposed metal with a suitable rust preventative (not supplied).
Ø38mm (11/2")
Ø29mm (11/8")
.
Page 6 of 36
215mm (8.46'')
320mm (12.6'')
holesaw. LHS shown,
Ø38mm (11/2")
130mm (5.1")
40mm (1.57'')
holesaw. LHS shown,
Ø29mm (11/8")
Issue 5: 20/09/23
