Section View - EGR ROLLTRAC RT038812E Installation Instructions Manual

For ford f-150 (including raptor & lighting) 5.5ft bed rhd&lhd - compatible with boxlink 2018 onwards

RHS MOUNT EXTRUSION ASSEMBLY

SPACER

SECTION VIEW

Check if the plastic spacers are in place, if they have fallen out during transport, please refit.

LHS MOUNT EXTRUSION ASSEMBLY

SPACER

SECTION VIEW

Check if the plastic spacers are in place, if they have fallen out during transport, please refit.

RT0046

Page 8 of 36

Issue 5: 20/09/23
