APPENDIX 1-2. Product Operation & Error History
The cumulative energization time, operation, and error history of NCW-3DHPN can be checked.
Index Name
Power Distribution Time
0x3000
0x3100 Event Log
Access Data
Read Write Type
○
- UDINT
○
- 256
(8[32])
65
Description
Indicates the cumulative energization time of NCW-3DHPN.
(Unit: sec)
Indicates the operation and error information histories of
NCW-3DHPN.
The history is stored in nonvolatile memory. (Max.32 histories)
Arrangement contents
Name Data Type
Message DWORD
code
UDINT
Event
occurrence
time
Remarks
History message code
Refer to next page.
Time when an event
occurs
