9-4. Set NameOfStation (Device Name)

The PROFINET configuration is needed setting each device name which is called "NamaOfStation".
The device name is previously set as a default name to the GSDML file.
Thus, the default name is displayed on the configuration tool. The configuration tool automatically adjusts the
device name if the same product name exists on the network.
Setting procedures are indicated below;
(1) In the "Network view" tab, double click the converter which is set the device name.
(1)
(1)
(2) Click the converter image when the "Device view" tab appears.
(3) Click "Ethernet Address" when "Properties" appears.
(2)
(2)
(3)
(3)
(3) (4)
