NSD ABSOCODER NCW-3DHPNM2R Specifications & Instruction Manual page 11

● Model List
◆Converter
No. Model
①
NCW-3DHPNM2R
◆ABSOCODER sensor
No. Model
MRE-[1]SP061FK[3]
MRE-[1]SP074[2] K [3][L]-G
MRE-[1]SP097[2] K [3][L]-G
MRE-[1]SP101[2] K [3][L]-G
[2]: Mounting format
F: Flange-mount type
(2)
K: Input shaft (sunk key)
[3]: Connector type
B: Standard connector for the NSD special cable
(NJW-2012-PM8, manufacturer: Nanaboshi Electric Mfg.Co,Ltd.)
P: Large connector for JKPEV-S cable (NWPC-4012-Ad12, manufacturer: Nanaboshi Electric Mfg.Co,Ltd.)
R: Crimping terminals for JKPEV-S cable and the NSD special cable (R1.25-4)
[L]: Interconnecting sensor cable length (m): 2, 5,10, 20
G: Silicon oil injected, no code: no oil injected
◆Extension sensor cable
No. Model
4P-S-0144-[L]
4P-RBT-0144-[L]
4P-URT-0144-[L]
4P-S-4344-[L]
4P-RBT-4344-[L]
4P-URT-4344-[L]
4P-HRT-4344-[L]
(3)
4P-S-0155-[L]
4P-RBT-0155-[L]
4P-URT-0155-[L]
4P-S-0190-[L]
4P-RBT-0190-[L]
4P-URT-0190-[L]
JKPEV-S(1.25mm
[L]: Specify the cable length (m) that you need.
◆Option
No.
(4) RB-01
◆GSDML
No.
File name:
(5)
GSDML-V***-NSD_Corporation-NCW3D_PN-********xml
For multi-turn type ABSOCODER sensor
Position data 17-bit binary code output
General environment type
Flange-mount type
With Interconnecting cable 2m
Compact size heavy duty type, SUS
Heavy duty type, cast iron
Heavy duty type, SUS
L: Base-mount type
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
2
×5P) Commercially available cable
Model
L-type flange for MRE-32SP061, MRE-G[ ]SP061
Model
Description
Description
[1]: Total number of turns
32, G64, G128, G160, G256, G320
[1]: Total number of turns
32, G64, G128, G160, G256, G320, G512,
G1280, G2048
[1]: Total number of turns
32, G64, G128, G160, G256, G320, G512,
G1280, G2048, G2560, G3072
M: Face-mount type (Only available for MRE-SP074)
Description
Standard connector
Large connector
Crimping terminals
Description
Download it from NSD website.
3
For JKPEV-S cable
Description
