NO.
Flat washer OD20 x ID10.5
Square end cap □38 (PRE-ASSEMBLED)
Square end cap □25 (PRE-ASSEMBLED)
Outer cap (PRE-ASSEMBLED)
Round cap φ19 (PRE-ASSEMBLED)
Square end cap □34 (PRE-ASSEMBLED)
Round cap φ25 (PRE-ASSEMBLED)
Square cap (PRE-ASSEMBLED)
EN
PARTS LIST
Description
Rear stabilizer
Weight plate Supporttube
Connect tube
Base frame
Front post
Support tube
Leg curl tube
Back rest support tube
Foam tube
Hex head bolt M10 x 50L
Hex head bolt M10 x 55L
Adjustment Rod
Nylon nut M10
Hex head bolt M6 x 35L
Flat washer OD18 x ID6.5
Back cushion
Hex head bolt M10 x 130L
Left safety hook
Hex head bolt M6 x 15L
Carriage bolt M8 x 50L
Flat washer OD18 x ID8.5
Nylon nut M8
Seat
Hex head bolt M8 x 15L
Right safety hook
Hex head bolt M10 x 60L
Foam Pad
Spring clip
Nylon nut M6
Elbow Support tube
Elbow cushion
Knob
Qty
