8.2 EDGE HEIGHT ADJUSTMENT
B
The edges should be 2 or 3 mm higher than the piece to be
edge banded. Cut the edges 5 or 6 cm longer than the piece
you are going to glue.
1. Edge entry:
A
To adjust the height of the edges A (Fig. 8) at the entry, adjust
the entry guide B. Insert the edge between the guides B. Loosen
the adjustment knob C and adjust the pressure foot D to the
height of the edge to be used according to the scale.
C
Fig. 8
D
2. Edge exit:
To adjust the height of the edges A (Fig. 9) at the exit, place
the edge as indicated in the figure and lock the position with
knob C.
C
Fig. 9
