Fig. 6
Fig. 7
18 - PEB Zeroline®
• Thicker edge banding requires more temperature.
• Thinner edge banding requires less pressure force for edge
banding.
• Thicker edge banding requires more pressure force for edge
banding.
7. PREPARATION AND CONNECTION OF THE
MACHINE
Proceed to the electrical and pneumatic connection of the
machine using the supplied hose into its electrical and pneu-
matic socket. For the electrical connection, remove the machine
socket from its holding device and connect the supply hose
socket onto it. (Fig. 6)
The machine requires a stable working pressure between 6-8
bar. As a safety measure, if the pressure drops below 4 bar or
if there is a loss of compressed air supply, the machine will
automatically shut off.
8. COLD MACHINE ADJUSTMENTS
8.1 GUIDE SUPPORT ADJUSTMENT
If you haven't done so during unpacking, assemble the guide
support A (Fig. 7) onto the bracket B and secure it with the
handle C. The height of the guide support A should be adjusted
according to the thickness of the piece to be edged D. To do
this, loosen the handle C and position the edge flush with the
C
A
D
top of the rod as indicated in (Fig. 7). When edging the
piece, there will be an excess of approximately 1.5 mm.
