1. Introduction
Thank you for your interest in the CY8CKIT-064B0S2-4343W PSoC 64 "Secure Boot" Wi-Fi BT
Pioneer Kit. The PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Kit enables you to evaluate and develop
your applications using the PSoC 64 Line of Secured MCUs (hereafter called PSoC 64) and
CYW4343W WICED Wi-Fi/BT combo device.
PSoC 64 is Cypress' latest, ultra-low-power PSoC specifically designed for wearables and IoT
products. PSoC 64 chip is a true programmable embedded system-on-chip, integrating a 150-MHz
® ®
Arm Cortex -M4 as the primary application processor, a 100-MHz Arm Cortex-M0+ that supports
low-power operations, pre-configured with a root-of-trust and secure processing environment, up to
2 MB Flash and 1 MB SRAM, Secure Digital Host Controller (SDHC) supporting SD/SDIO/eMMC
TM
interfaces, CapSense touch-sensing, and programmable analog and digital peripherals that allow
higher flexibility, in-field tuning of the design, and faster time-to-market.
The PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Board offers compatibility with Arduino™ shields. The
board features a PSoC 64 chip, and a CYW4343W Wi-Fi/BT combo module. Cypress CYW4343W
is a highly integrated single-chip solution that includes a 2.4 GHz WLAN IEEE 802.11 b/g/n MAC/
baseband/radio and Bluetooth 5.1 support. The WLAN section supports SDIO interface to the host
MCU (PSoC 64), and the Bluetooth section supports high-speed 4-wire UART interface to the host
MCU. In addition, the board features an onboard programmer/debugger (KitProg3), a 512-Mbit
Quad SPI NOR flash, a 4-Mbit Quad SPI F-RAM, a micro-B connector for USB device interface, a 5-
segment CapSense slider, two CapSense buttons, a microSD card holder, an RGB LED, two user
LEDs, one potentiometer, and two push buttons. The board supports operating voltages of 1.8 V, 2.5
V and 3.3 V.
TM
You can use ModusToolbox software to develop and debug your PSoC 64 projects.
ModusToolbox software is a set of tools that enable you to integrate Cypress devices into your
existing development methodology.
If you are new to PSoC 6 MCU and ModusToolbox software, refer to the application note AN228571
- Getting Started with PSoC 6 MCU on ModusToolbox to help you familiarize with the PSoC 6 MCU
and help you create your own design using the ModusToolbox software.
