CY8CKIT-064B0S2-4343W PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E
Arrow.com.
Downloaded from
Table 1-1. PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Board Pinout
Primary On-board
Pin
Function
XRES Hardware Reset
P0[2] GPIO on non-Arduino
header IO0 (J22.1)
P0[3] GPIO on non-Arduino
header IO1 (J22.2)
P0[4] User button (SW2)
with Hibernate
wakeup capability
P0[5] RGB green LED
(LED5)
P1[0] CapSense RX for
buttons and
CapSense TX for
sliders
P1[1] RGB red LED (LED5) GPIO on non-Arduino
P1[2] USB Host Enable
P1[3] GPIO on non-Arduino
header IO2 (J22.3)
P1[4] User button (SW4)
with Hibernate
wakeup capability
P1[5] Orange user LED
(LED8)
P5[0] UART_RX
P5[1] UART_TX
P5[2] UART_RTS
P5[3] UART_CTS
P5[4] Arduino D4 (J4.5)
P5[5] Arduino D5 (J4.6)
P5[6] Arduino D6 (J4.7)
P5[7] Arduino D7 (J4.8)
P6[0] I2C SCL
P6[1] I2C SDA
P6[2] USB VBUS Detect
P6[3] USB Interrupt
Secondary On-board
Function
PSoC 64 Pins
– –
– –
– –
GPIO on non-Arduino –
header (J21.9)
GPIO on non-Arduino –
header (J24.3)
GPIO on non-Arduino Remove R33 to disconnect from CapSense.
header IO7 (J22.8)
Populate R145 to connect to GPIO on non-
Arduino header.
–
header (J24.1)
– –
– –
GPIO on non-Arduino –
header (J21.10)
GPIO on non-Arduino –
header (J24.2)
Arduino D0 (J4.1) Remove R21 to disconnect from KitProg3.
Populate R115 to connect to GPIO on non-
Arduino header.
Arduino D1 (J4.2) Remove R61 to disconnect from KitProg3.
Populate R116 to connect to GPIO on non-
Arduino header.
Arduino D2 (J4.3) Remove R19 to disconnect from KitProg3.
Arduino D3 (J4.4) Remove R18 to disconnect from KitProg3.
– –
– –
– –
– –
Arduino (J3.10) Remove R58 to disconnect from KitProg3.
Arduino (J3.9) Remove R59 to disconnect from KitProg3.
– –
– –
Introduction
Connection details
11
