1.2
1.3
1.4
CY8CKIT-064B0S2-4343W PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Kit Guide, Document Number: 002-29286 Rev. *E
Arrow.com.
Downloaded from
Getting Started
This guide will help you get acquainted with the PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Kit:
The Software Installation chapter on page 18
■
includes the ModusToolbox software which will be used to develop, program and debug
applications on to the device.
The Kit Operation chapter on page 20
■
Boot" Wi-Fi BT Pioneer Kit and functionalities such as programming, debugging, and the USB-
2
UART and USB-I C bridges.
The Running Code on PSoC 64 "Secure Boot" MCUs chapter on page 29
■
PSoC 64 code examples that will help you understand how to create your own PSoC 64 projects.
The Hardware chapter on page 40
■
onboard NOR flash, kit schematics, and the bill of materials (BOM).
Application development using PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Kit is supported in vari-
■
ous development ecosystems such as ModusToolbox software and Mbed OS. For the latest soft-
ware support for this development kit including the different development ecosystems, refer to
the kit webpage.
ModusToolbox software is a free development ecosystem that includes the ModusToolbox
❐
IDE. Using ModusToolbox IDE, you can enable and configure device resources, middleware
libraries, and program and debug the device. You can download the software from the
Toolbox home page. See the ModusToolbox User Guide for additional information.
Mbed OS: Visit Cypress' Mbed OS page
❐
target board on the Mbed OS platform.
Code Examples
There are wide range of code examples to evaluate the PSoC 64 "Secure Boot" Wi-Fi BT Pioneer
■
Board.These examples help you familiarize PSoC 64 "Secure" MCU and create your own design.
These examples are available in various development ecosystems such as ModusToolbox IDE
and Mbed OS. Visit Cypress' code example page to access examples for the following develop-
ment ecosystems:
ModusToolbox software based examples
❐
Mbed OS based examples
❐
Board Details
The PSoC 64 "Secure Boot" Wi-Fi BT Pioneer Board has the following features:
■ CY8CMOD-064B0S2-4343W board contains:
PSoC 64 device (CYB0644ABZI-S2D44)
❐
Murata Type 1DX ultra-small 2.4-GHz WLAN and Bluetooth functionality module based on
❐
CYW4343W
512-Mbit external Quad SPI NOR Flash that provides a fast, expandable memory for data and
■
code
4-Mbit Quad SPI ferroelectric random-access memory (F-RAM)
■
KitProg3 onboard SWD programmer/debugger with USB-UART and USB-I2C bridge functionality
■
CapSense touch sensing slider (5 elements) and two buttons. The slider and buttons are capable
■
of using self-capacitance (CSD) or mutual-capacitance (CSX) sensing methods.
A second Micro-B connector for USB device interface
■
describes the installation of the kit software. This
describes the major features of the PSoC 64 "Secure
provides a detailed hardware description, methods to use the
on instructions to develop applications on Cypress'
Introduction
describes multiple
Modus-
